24 keys IR Remote DC12-24V 3x2A LED RGB Controller

*Summarization
24-key infrared controller adopts the advanced micro control unit,it is used for controlling a variety of lamp
whose source of light is LED. For instance, point source of light,flexible light strip, wall washer lamp, glass
curtain wall light and so on; it has many advantages such as low price, easy connection and simplicity to
use.Meanwhile,you could adjust brightness, static color choices and various dynamic changes in lighting
effects through infrared remote control.

*Technical Parameters
● Working temperature：-20-60 ℃
● Supply voltage: DC5V, 12V, 24V <optional >(for orders specify voltage)
● 0utput: 3 channels
● Connecting mode：common anode
● External dimension：L63ΧW35ΧH22 mm
● Packing size：L105ΧW65ΧH40 mm
● Net weight: 50 g
● Gross weight: 70 g
● Static power consumption: <1 W
● Output current: <2 A (each channel)
● Output power: 5 V: <30W, 12V: <72W, 24V: <144W
