LED Mini Amplifier 6A DC12-24V For Single Color LED 3528 5050 Flexible Strip Lighting

Specification:

Single Color amplifier, which can receive PWM ( Pulse Width Modulation), applies to all the voltage-controlled and power-limited controller of LED ligtings. If adding one Single Color amplifier each time, the quntity of LED lightings which is interconnected will be increase more than twice, even numerous!

•Working temperature : -20~60 degree
•Working voltage : DC12V-24V
•Output power : 12V:<72W; 24V:<144W
•Product Size : L64*W35*H23mm
•Net weight : 30g
•Gross weight : 80g
•Output : 2 CMOS drain-open output
•Connecting mode : Common anode
•Max output current : 3A each color

Applications:
Be used for Single Color 5050 3528 LED strip, rigid bar, Single Color wall washer, Single Color underwater lamp, Single Color underground light etc.

Safety Information:
1 The input voltage of this controller should be follow the specifications, other high voltage would most probably destroy it.
2 All connecting wires can not be incorrectly interconnected, or short circuit could occur.
3 The standard warranty is one year. Our factory won't be responsible for any damage of the controller due to any wrong operation.
