DC12V/24V 3x4A IR Remote RGB LED Lighting Music Controller

Summarization:



1. RF Audio controller adopts the advanced micro control unit, it is used for controlling

2. a variety of lamp whose source of light is LED. For instance, point source of light,

3. flexible light strip, wall washer lamp, glass curtain wall light and so on; At the same time,

4. it has many advantages such as convenient connection, simplicity to use and others.

5. According to the actual need of customers, it can carry out jumpy changing, gradual changing, stroboflash and other effects of change.

 6. sound control music light

 7. sound activated light control

Technical Parameters

1. Operating temperature: -20 to +45 degreen
2. Working voltage: 12-24V DC adapter or battery
3. Output: 3 channels (RGB)
4. Control variant: common anode
5. Sound control:> 70dB
6. Output current: 3*4A

Operating instructions:

  sound control music light

1) Turn ON/OFF button, you can switch on the RGB LED strip.

2) Slide the color ring, RGB strip will show the same color

3) Gradual change model: Touch on button again under monochrome mode condition, RGB strip will be changed into gradual change mode .increasing color button will speed up the color change, decreasing color button will slowdown.

4) Hopping mode: Under gradual change mode condition. Touch on button .the RGB strip will be changed into hopping mode. Increasing color button will speed up the hopping, decreasing color button will slowdown.

5) Under gradual change or hopping mode, touching on switch will change one to the other. Close the RGB strip and restart It if you want to enter monochrome mode.

6) You can adjust the brightness by dimming function, to brighten, and dim the light

7)   sound control music light ,  sound activated light control.
